Waveguide |
coatial |
|
|
Frequency rate |
14GHz |
2.0GHz |
|
Peak power |
10kW max. |
3kW max. |
|
Average power |
100W max. |
200W max. |
|
VSWR |
1.2 max. |
1.2max. |
|
VSWR-WOW |
0.1 max. |
0.05max. |
|
Insertion loss |
0.2db max |
0.4db max |
|
Insertion loss WOW |
0.05db max. |
0.1db max. |
|
Interfaces |
R120°special flange |
SMA-F(50Ω) |
|
Insolation |
60 db max |
60 db max |
|
Phase WOW |
1° max. |
1° max. |
|
speed |
60rpm |
60rpm |
|
life |
10,000,000 revolutions |
|
|
Torque |
0.2 N.m |
|
|
Weigt |
0.6kg |
|
|
Operation temp. |
-40℃~+80℃ |
|
|
Humidity |
95% |
|
|
Seal class |
IP64 |
|
